CNC Wood Router With Saw Cutting CNC Router Machine For Wood And Metal CNC Wood Router Carpenter Machine Table Size
Briefing
The product is a CNC Wood Router with Saw Cutting. This machine is designed for efficient and precise cutting and routing of wood using CNC technology and a saw blade mechanism.
Key Specifications
- Type: CNC Wood Router with Saw Cutting
- Material: Steel
- Operation: Automatic
- Power: 9.0 kW air-cooled spindle + 3.0 kW saw spindle
- Voltage: 220V/380V
- Cutting Capacity: Varies based on model
- Rotary Speed: 0-24000 RPM
- Weight: Varies based on model
- Dimensions: Customizable
- Control: Electric with CNC control system
Applications
- Woodworking: Ideal for cutting and routing wood in various woodworking projects.
- Furniture Manufacturing: Suitable for manufacturing furniture and decorative items.
- Signage: Can be used for cutting and routing materials for signage.
- Customizable: Can be customized for different sizes and specifications.
Summary
This CNC wood router with saw cutting offers a powerful and efficient solution for cutting and routing wood. It is designed for automatic operation with a high-precision CNC control system, making it suitable for use in various industries such as woodworking, furniture manufacturing, and signage. The machine is customizable in terms of size and specifications, providing flexibility for different projects. Its durable construction and advanced control features ensure reliable performance.
Product Detail
BCM1325E series is a cnc router designed by BCAM for automatic disc changer. This series is more automatic than BCM1325A manual tool change series. It is faster than BCM1325C series tool change, eliminating manual The cumbersome tool change shortens the tool change time and makes the cnc router more precise.
Product parameters
|
Parameters
|
Standard Specifications BCM1325E Plus
|
|
X,Y,Z Working Area
|
1300*2500*200mm|4*8ft
|
|
Optional Working Area
|
1300*1300*200mm|4*4ft
|
|
Optional Working Area
|
1500*3000*200mm|5*10ft
|
|
Optional Working Area
|
2000*3000*200mm|7*10ft
|
|
Spindle Power
|
9kw Italy HSD air cooling spindle
|
|
Table Surface
|
Vacuum table
|
|
Max. Rapid Travel Rate
|
80m/min
|
|
Max. Working Speed
|
45m/min
|
|
Drive Motors
|
4 sets 750w Yaskawa servo motor and drivers
|
|
Working Voltage
|
AC380v/50HZ/3 phase
|
|
Command Language
|
G Code
|
|
Operating System
|
Taiwan Syntec 6MB control system
|
|
Interface
|
USB,NETWORK
|
|
Software Compatibility
|
Option:Alpacam/CaGTMnets Version/BCAMNESTTING/Solidworks,etc.
|
|
Running Environment
|
Temperature: 0℃~45℃ Relative Humidity: 30%~75%
|
Samples
