Automotive Service Equipment & Wheel Alignment Combo
| Technology parameter | |||
| Max. Wheel Diameter | 1120mm(44″) | Frequency | 50/60Hz |
| Max. Wheel width | 356mm(14”) | Working pressure | 8-12 bar |
| Inside chuck size | 12”-26″ | Bead breaker power per cylinder | 2800kg |
| Outside chuck size | 10″-24″ | Rotate speed | 6-12rpm |
| Power supply | 220V 1PH/380V 3PH | Net weight |
247kg |
Key attributes
Other attributes
Motor Power – 0.75kw/1.1kw/0.55w
Operating Pressure – 8-12bar
Power Supply – 380V/3PH/50-60Hz
Brand Name – Roadbuck
Model Number – GT325 L
Warranty – 1 Years
Certification – CE / ISO9001
Work pressure – 8-12bar
Max wheel diameter – 1120mm(44″)
Max wheel width – 356mm(14″)
NOISE LEVEL – 75dB
Outside clamping – 10″-24″
Inside clamping – 12″~26″
Bead breaker force – 2800KG
Frequency – 50/60Hz
Rotation Speed – 6-12rpm
Packaging and delivery
Packaging Details – Carton & wooden case
Selling Units: – Single item
Single package size: – 112X80X178 cm
Single gross weight: – 68.000 kg
